• Yamaha CZR10 10-Inch Passive Speaker
1 1

Yamaha CZR10 10-Inch Passive Speaker | Color: Black

Yamaha CZR10 10-Inch Passive Speaker | Color: Black

SoundPro Item: 34561 | Part Number: CZR10

$789.99
$1,184.00 $789.99
Your Price Sold out
MSRP: $1,184.00 | MAP: $789.99

Usually ships in 5-7 business days

  • 2-way loudspeaker with a 2” HF and a 10" LF
  • Features Yamaha's own Wide Dispersion CD Waveguide Horn
  • High power 700W(PGM) power handling and Bi-amp capable
  • Floor monitoring setting
  • Lightweight yet very durable plywood cabinet with premium graded Polyurea coating
  • Dual-angle pole socket
  • Optional speaker cover (SPCVR-DZR10)
  • Rotatable horn and variety of U-bracket options (UB-DZR10H/V) for rigging allow for very flexible setup and speaker placement
  • Durable Black or White finish
Log in or register for YOUR best price

The CZR10 is a 2-way loudspeaker offering high power handling and outstanding sonic performance in a portable, lightweight, yet rugged design. Its versatile, compact enclosure design makes the lightweight CZR10 ideal for range of live performance and installed sound environments—from live bands at outdoor festivals to DJs in clubs—these loudspeakers deliver crystal clear, high-quality sound with impressive low frequency performance.

View full details
  • Speaker type2-way Speaker, Bass-reflex
  • Frequency range (-10dB) Passive: 43 Hz - 20 kHz, Normal (*1): 46 Hz - 20 kHz, FOH (*1): 43 Hz - 20 kHz
  • Coverage areaH90° x V60° Rotatable Constant Directivity Horn
  • Floor Monitor Angle50° Symmetrical
  • Components
    • LF: 10" Cone, 3" Voice Coil, Neodymium magnet
    • HF: 2" Voice Coil, 1" Throat Compression Driver, Titanium diaphragm, Neodymium magnet
  • Crossover2.5 kHz
  • Power rating
    • NOISE: Passive (EIA 426-A) 400 W, Bi-amp LF (EIA 426-A): 400W, HF (AES): 50W
    • PGM: Passive (EIA 426-A) 800 W, Bi-amp LF (EIA 426-A): 800W, HF (AES): 100W
    • PEAK: Passive (EIA 426-A) 1600 W, Bi-amp LF (EIA 426-A): 1600W, HF (AES): 200W
  • Nominal impedancePassive: 8Ω, Bi-amp: LF: 8Ω, HF: 16Ω
  • SPL
    • Sensitivity (1W; 1m on axis): Passive: 97dB SPL, Bi-amp: LF: 97dB SPL, HF: 108dB SPL
    • Peak (Calculated): Passive: 129 dB SPL, Bi-amp: LF: 129dB SPL, HF: 131dB SPL
  • I/O connectorsSpeakON NL4MP x 2 (Parallel)
  • HandleAluminium die-cast, Side x2
  • Pole socketΦ35 mm x2 (0° or -7°)
  • RiggingM10 x 12
  • Dimensions
    • W: 410 mm (16.1")
    • H: 646 mm (25.4") (with rubber feet)
    • D: 394 mm (15.5")
  • Net weight18.0 kg (39.7 lbs)
  • OptionsBracket: UB-DZR12H/V, Cover: SPCVR-DZR12
  • OthersEnclosure Material, Finish, Color: Plywood, Durable Polyurea coating, Black/White
