Specifications
Dimensions
Dimensions (WxHxD)
18.7x13.5x17.9"
Electrical
Power Consumption
74 W (1/8power), 18 W (Idle)
Power Requirements
100 V, 100-120 V, 220-240 V, 110/127/220 V (Brazil), 50/60 Hz
Audio
Speaker Type
2-way, Bi-amped Powered Speaker, Bass-reflex
Crossover
1.8 kHz: FIR-X tuning™ (linear phase FIR filter)
OUTPUT
XLR3-32 x 1 (CH1 Parallel Through or CH1+CH2 Mix)
Connectivity
Max. Output Level (measured Peak, IEC Noise @1m)
129 dB SPL
Pole Socket
Φ35 mm x1 (Bottom)
Construction
Amplifier Class
Class D
Cabinet Material
plywood
Finish
durable polyurea painting, black
Included Items
Components
LF, HF
Shipping
Weight
36.4 pounds
General
Frequency Range (-10dB)
55Hz - 20,000Hz
Coverage Area (HxV)
90° x 90°
Dynamic
1,000 W (LF: 800 W, HF: 200 W)
Continuous
465 W (LF: 400 W, HF: 65 W)
Cooling
fan cooling, 4 speeds
A/D D/A Converters
24 bit 48 kHz Sampling
HPF
OFF, 100 Hz, 120 Hz, 24 dB/Oct
D-CONTOUR
FOH/MAIN, MONITOR, OFF
INPUT2
Combo x 1 + RCA pin x 2 (Unbalanced)
Handle
side (1)
Floor Monitor Angle
57°
Inputs
INPUT1
Combo x1
