Specifications
Dimensions
Dimensions (WxHxD)
7.3x5.1x3.7” (184x130x94mm) *2
Weight
Net Weight
1.0kg (2.2lbs), 1.1kg (2.4lbs)*4
Audio
Speaker Type
Full-range, Acoustic suspension
Sensitivity (1W; 1m on axis)
86dB SPL *1
Connectivity
I/O Connectors
1x Euroblock (4P) (Input: + / -, Loop Thru: + / -)
Construction
Finish
VXS3F: Black (approx. Munsell N3), VXS3FW: White (approx. Munsell N9)
General
Frequency Range (-10dB)
130Hz -20kHz
H
150°
V
160°
Components (LF-HF)
3.5" Cone
NOISE
20W
PGM
40W>
PEAK
80W
Nominal Impedance
8Ω
Peak (Calculated)
105dB SPL
Protection Circuit (Load protection)
Full-range power limiting for protecting network and transducers
Certificate
UL1480, NFPA70, CE, RoHS
*1
Full-space(4π), 200Hz to 10kHz pink noise
*2
In horizontal cabinet setup
*3
with bracket (in 0° setup)
*4
with bracket
