Specifications
Dimensions
External Dimensions (HxDxW)
156x130x42 mm
External Dimensions (DxWxH)
177×23×25mm
Audio
Output
Standard stereo phone jack (combined line/headphone)
Maximum Output Level
Line +2 dBu (10 kΩ or more output impedance)Headphones 17 mW + 17 mW (32Ω load)
Connectivity
Input
Standard mono phone jack
Rated Input Level
-20 dBuInput impedance (line): 470 kΩ
Input S/N
120dB
Nominal Output Level
−20 dBuMaximum output level: +7 dBuOutput impedance: 1 kΩ
Shipping
Weight
340 g (excluding batteries)
General
Max. Number of Simultaneous Effects
5
User Patches
50
Sampling Frequency
44.1 kHz
A/D Conversion
24-bit, 128× oversampling
D/A Conversion
24-bit, 128× oversampling
Signal Processing
32-bit
AUX IN
Stereo mini jack
Noise Floor (Residual Noise)
-97 dBu
MAA-1
Continuous operation time (when phantom current is 3 mA): About 15 hours (using alkaline batteries or nickel metal hydride batteries), 0 dBu = 0.775 V
Indicators
Display
128x32 dot matrix LCD
Power
Power
AC adapter: 9V DC 500mA center negative (ZOOM AD-16) 4 AA batteries (about 18 hours continuous operation time when using alkaline batteries with the LCD backlight off) USB USB MIDI, USB Micro-B Power can also be supplied through the USB port.When using a cable designed only for power, other USB functions cannot be used.
