dbx DriveRack PA2 Speaker Management System
dbx DriveRack PA2 Speaker Management System
SoundPro Item: 18172 | Part Number: PA2
In stock and ready to ship
- dbx Compression
- AFS™ (Advanced Feedback Suppression)
- Graphic EQ
- 8-Band Parametric EQ (adjusted when using the AutoEQ)
- Subharmonic Synthesis
- Crossover (supports full range, 2-way, and 3-way systems)
- 8-Band Parametric EQs (used for speaker tunings)
- dbx Limiting
- Driver Alignment Delays
The DriveRack PA2 provides all the processing you need between your mixer and amplifiers to optimize and protect your loudspeakers. With the latest advancements in dbx's proprietary AutoEQ and AFS algorithms, a new input delay module for delaying the FOH system to the backline, Ethernet control via an Android, iOS, Mac, or Windows device, and updated Wizards, the DriveRack PA2 continues the DriveRack legacy of great-sounding, powerful, and affordable loudspeaker management processors, for a whole new generation.
- Tested wireless routersDlink 636L, Dlink Cloud router 2000, Cisco / linksys WRT54G2V1, Netgear WGR614 v7 and WNR 1000
- Inputs(2) line inputs, (1) RTA mic input
- Input connectors(2) female XLR line inputs, (1) female XLR RTA mic input
- Input typeelectronically balanced/RF filtered
- Input impedance>50 kohm
- A/D converterdbx Type IV™ Conversion System
- Converter dynamic range112 dB A-weighted, 110 dB unweighted (same for A/D and D/A)
- CMRR> 45dB
- Mic preamp EIN< -117dB, 22Hz-22kHz, 150 ohm (RTA)
- Output(6) line outputs
- Output connectorsmale XLR
- Output typeelectronically balanced, RF filtered
- Output impedance120 Ω
- Max output+20dBu
- Input delay length100ms
- Alignment delay10ms per channel (60ms total)
- Sample rate48kHz
- Dynamic range>110 dB A-weighted, >107dB unweighted
- THD+Noise0.003% typical at +4dBu, 1kHz, 0dB input gain
- Frequency response20Hz – 20kHz, +/- 0.5dB
- Operating voltage100-120VAC 50/60 Hz
- Power consumption22 W
