- e 614
- Dimensions: Ø 20mm, L = 100mm
- Connector: XLR-3
- Frequency response: 40 - 20000 Hz
- Max. sound pressure level: 139 dB/SPL
- Transducer principle: pre-polarised condenser microphone
- Weight: 93 g
- Pick-up pattern: super-cardioid
- Sensitivity in free field, no load (1kHz): 3 mV/Pa = - 50dB (0 dB = 1 V/Pa)
- Nominal impedance: 50 Ω
- Min. terminating impedance: 1000 Ω
- Phantom powering: 12 – 52 V / 3 mA
- Equivalent noise level: 24 dB(A)
- Equivalent noise level weighted as per CCIR: 35 dB
- 602 ii
- Dimensions: Ø 60 x 153 mm
- Connector:XLR-3
- Transducer principle (Microphone): dynamic
- Frequency response: 20 - 16000 Hz
- Weight: 318 g
- Pick-up pattern: cardioid
- Sensitivity in free field, no load (1kHz): 0,25 mV/Pa; (50 Hz) 0,9 mV/Pa
- Nominal impedance: 350 Ω
- Min. terminating impedance: 1000 Ω
- e 604
- Dimensions: Ø 33x59mm
- Connector: XLR-3
- Frequency response (Microphone): 40 - 18000 Hz
- Transducer principle (Microphone): dynamic
- Weight: 60 g
- Pick-up pattern: cardioid
- Sensitivity in free field, no load (1kHz): 1,8 mV/Pa
- Nominal impedance: 350 Ω
- Min. terminating impedance: 1000 Ω
- Weight w/o cable: 60 g
