- Dimensionsapprox. 63×47×20 mm
- THD, total harmonic distortiontyp. 0.002%
- WeightApprox. 112 g (with BA 62 battery pack, antenna and beltclip)
- Audio input3-pin audio socket
- Signal-to-noise ratiotyp. 113 dB(A)
- RF output power
- standard mode: 15 mW rms
- low power mode: 3.5 mW rms
- Switching bandwidthup to 88 MHz
- Operating timetyp 12 h at 25° C (with BA 62 accupack)
- Frequency range
- 470.200 to 713.800 MHz:
- A1-A4 (470.200 – 558.000 MHz)
- A5-A8 (550.000 – 638.000 MHz)
- B1-B4 (630.000 – 713.800 MHz)
- A5-A8 US (550.000 – 607.800 MHz)
- B1-B4 AU (630.000 – 693.800 MHz)
- Audio codec
- SeDAC (Sennheiser Digital Audio Codec)
- SePAC (Sennheiser Performance Audio Codec)
- Frequency stability< 5 ppm
- Tunability25 kHz steps
- Lower cut-off-frequencyadjustable: 30 Hz, 60 Hz, 80 Hz, 100 Hz, 120 Hz
- Encryption AES 256
- Audio frequency response30Hz-20kHz (-3 dB)
- Audio GainMic: adjustable in 3 dB steps from −6 dB to +42 dB
- Modulation scheme
- Digital modulation Long Range Mode
- Digital modulation Link Density Mode
- Antenna OutputCoaxial socket
